SMC Networks LECSN-T Series

5. PARAMETERS
5 - 95
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PT65
PVC
Profile speed
command
Set the speed of the profile speed command. The fractional portion of the parameter
will be rounded down. The setting value will be clamped at the instantaneous
permissible speed.
This function will be enabled in the profile position mode (pp).
This parameter corresponds to "Profile velocity (Class ID: 64h, Ins ID: 6081h, Attr
ID: 0)". When this parameter is mapped for the I/O communication, the value written
with Setup software (MR Configurator2
TM
) is overwritten with the upper side. Thus,
do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.00 to 167772.15
100.00
[r/min]/
[mm/s]
Set the speed of the profile speed command. The fractional portion of the parameter
will be rounded down. The setting value will be clamped at the instantaneous
permissible speed.
This function will be enabled in the profile position mode (pp), Jog mode (jg) and
indexer mode (idx).
This parameter corresponds to "Profile velocity (PNU: 24705, Sub: 0)". When this
parameter is mapped for the Process Data communication, the value written with
Setup software (MR Configurator2
TM
) is overwritten with the upper side. Thus, do
not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.00 to 167772.15
100.00
[r/min]/
[mm/s]
PT66
MPVC
Maximum
profile speed
Set the maximum profile speed.
This function will be enabled in the profile position mode (pp), profile velocity mode
(pv), Jog mode (jg) and indexer mode (idx).
The fractional portion of this parameter will be rounded down in the profile position
mode (pp), Jog mode (jg) and indexer mode (idx).
This parameter corresponds to "Max profile velocity (Index: 607Fh)". When this
parameter is mapped for the PDO communication, the value written with Setup
software (MR Configurator2
TM
) is overwritten with the upper side. Thus, do not write
a value with Setup software (MR Configurator2
TM
).
Setting range: 0.00 to 20000.00
20000.00
[r/min]/
[mm/s]
Set the maximum profile speed.
This function will be enabled in the profile position mode (pp) and profile velocity
mode (pv).
The fractional portion of this parameter will be rounded down in the profile position
mode (pp).
This parameter corresponds to "Max profile velocity (Class ID: 64h, Ins ID: 607Fh,
Attr ID: 0)". When this parameter is mapped for the I/O communication, the value
written with Setup software (MR Configurator2
TM
) is overwritten with the upper side.
Thus, do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.00 to 20000.00
20000.00
[r/min]/
[mm/s]
Set the maximum profile speed.
This function will be enabled in the profile position mode (pp), profile velocity mode
(pv), Jog mode (jg) and indexer mode (idx).
The fractional portion of this parameter will be rounded down in the profile position
mode (pp), Jog mode (jg) and indexer mode (idx).
This parameter corresponds to "Max profile velocity (PNU: 24703, Sub: 0)". When
this parameter is mapped for the Process Data communication, the value written
with Setup software (MR Configurator2
TM
) is overwritten with the upper side. Thus,
do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 0.00 to 20000.00
20000.00
[r/min]/
[mm/s]
