11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 32
(3) Dimensions
(a) EMC filter
HF3010A-UN
[Unit: mm]
32 ± 2
85 ± 2
110 ± 4
258 ± 4
273 ± 2
288 ± 4
300 ± 5
M4
IN
3-M4
65 ± 4
Approx. 41
4-5.5 × 73-M4
HF3030A-UN/HF-3040A-UN
[Unit: mm]
F ± 2
G ± 1
A ± 5
H ± 2
J ± 2
E ± 1
D ± 2
3-L
6-K
3-L
M
C ± 1
B ± 2
C ± 1
Model
Dimensions [mm]
A
B
C
D
E
F
G
H
J
K
L
M
HF3030A-UN
260
210
85
155
140
125
44
140
70
R3.25 length: 8
M5
M4
HF3040A-UN
