19．EtherNet/IP COMMUNICATION
(1) External Output pin display (2C11h)
Ins ID
Attr ID
Access
Name
Data Type
2C11h
0
Get
Number of entries
USINT
1
External Output pin display1
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2C11h
0
2
02h to 02h
Impossible
1
0
00000000h to 0000000Fh
The ON/OFF state of external output pins output from the driver can be read.
This object is available with drivers.
The following shows the detail of External Output pin display1. When the output of the target pin is on, "1"
is returned. When the output of the target pin is off, "0" is returned. The values in the areas marked with
diagonal lines at reading is undefined.
Bit
CN3 connector pin
Bit
CN3 connector pin
Bit
CN3 connector pin
Bit
CN3 connector pin
0
13
8
16
24
1
15
9
17
25
2
9
10
18
26
3
8
11
19
27
4
12
20
28
5
13
21
29
6
14
22
30
7
15
23
31
(2) Power ON cumulative time (2C18h)
Ins ID
Attr ID
Access
Name
Data Type
2C18h
0
Get
Power ON cumulative time
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2C18h
0
00000000h to FFFFFFFFh
hour
Impossible
The cumulative energization time of the driver is returned.
(3) Number of inrush relay on/off times (2C19h)
Ins ID
Attr ID
Access
Name
Data Type
2C19h
0
Get
Number of inrush relay on/off times
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
2C19h
0
00000000h to FFFFFFFFh
number of times
Impossible
The number of on/off times of the inrush relay of the driver is returned.
