19 - 177
19．EtherNet/IP COMMUNICATION
(5) SI unit position (60A8h)
Ins ID
Attr ID
Access
Name
Data Type
60A8h
0
Get/Set
SI unit position
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
60A8h
0
0
Refer to the text.
pos units
Impossible
SI unit position (Class ID: 64h, Ins ID: 60A8h, Attr ID: 0) is set automatically with the control mode, [Pr.
PT01] and [Pr. PT03].
[Pr. PT01] setting
[Pr. PT03] setting
Range
_ 0 _ _ (mm)
_ _ _ 0 (× 1)
FA010000h (0.001 mm)
_ _ _ 1 (× 10)
FB010000h (0.01 mm)
_ _ _ 2 (× 100)
FC010000h (0.1 mm)
_ _ _ 3 (× 1000)
FD010000h (1 mm)
_ 1 _ _ (inch)
_ _ _ 0 (× 1)
FCC00000h (0.0001 inch)
_ _ _ 1 (× 10)
FDC00000h (0.001 inch)
_ _ _ 2 (× 100)
FEC00000h (0.01 inch)
_ _ _ 3 (× 1000)
FFC00000h (0.1 inch)
_ 2 _ _ (degree)
_ _ _ 0 to _ _ _ 3
FD410000h (0.001 degree)
_ 3 _ _ (pulse)
00000000h (1 pulse)
(6) SI unit velocity (60A9h)
Ins ID
Attr ID
Access
Name
Data Type
60A9h
0
Get/Set
SI unit velocity
UDINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
60A9h
0
0
FB010300h (0.01 mm/s)
FEB44700h (0.01 r/min)
vel units
Impossible
The SI unit velocity is returned.
