19 - 179
19．EtherNet/IP COMMUNICATION
(4) Touch probe pos1 neg value (60BBh)
Ins ID
Attr ID
Access
Name
Data Type
60BBh
0
Get
Touch probe pos1 neg value
DINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
60BBh
0
0
80000000h to 7FFFFFFFh
pos units
Impossible
The position latched at the falling edge of touch probe 1 is returned.
(5) Touch probe pos2 pos value (60BCh)
Ins ID
Attr ID
Access
Name
Data Type
60BCh
0
Get
Touch probe pos2 pos value
DINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
60BCh
0
0
80000000h to 7FFFFFFFh
pos units
Impossible
The position latched at the rising edge of touch probe 2 is returned.
(6) Touch probe pos2 neg value (60BDh)
Ins ID
Attr ID
Access
Name
Data Type
60BDh
0
Get
Touch probe pos2 neg value
DINT
Ins ID
Attr ID
Default
Range
Units
EEP-ROM
Parameter
60BDh
0
0
80000000h to 7FFFFFFFh
pos units
Impossible
The position latched at the falling edge of touch probe 2 is returned.
