19．EtherNet/IP COMMUNICATION
(2) Digital outputs (60FEh)
Ins ID
Attr ID
Access
Name
Data Type
60FE
0
Get
Number of entries
USINT
1
Get/Set
Physical outputs
UDINT
2
Bit mask
Ins ID
Attr
ID
Default
Range
Units
EEP-ROM
Parameter
60FE
h
0
2
02h to 02h
Impossible
1
0
00000000h to 000E0000h
2
0
Set the ON/OFF states of the output devices connected to the driver.
This object is available with drivers.
(a) Physical outputs (Class ID: 64h, Ins ID: 60FEh, Attr ID: 1)
Bit
Description
0 to 16
(reserved) The value at reading is undefined. Set "0" when writing.
17
DO1
0: DOA (General-purpose output A) off
1: DOA (General-purpose output A) on
When using this bit, assign DOA (General-purpose output A) to CN3-9, CN3-13 or
CN3-15 pin in [Pr. PD07] to [Pr. PD09].
18
DO2
0: DOB (General-purpose output B) off
1: DOB (General-purpose output B) on
When using this bit, assign DOB (General-purpose output B) to CN3-9, CN3-13 or
CN3-15 pin in [Pr. PD07] to [Pr. PD09].
19
DO3
0: DOC (General-purpose output C) off
1: DOC (General-purpose output C) on
When using this bit, assign DOC (General-purpose output C) to CN3-9, CN3-13 or
CN3-15 pin in [Pr. PD07] to [Pr. PD09].
20 to
31
(reserved) The value at reading is undefined. Set "0" when writing.
(b) Bit mask (Class ID: 64h, Ins ID: 60FEh, Attr ID: 2)
Bit
Description
0 to 16
(reserved) The value at reading is undefined. Set "0" when writing.
17
DO1
0: DOA (General-purpose output A) disabled
1: DOA (General-purpose output A) enabled
When this bit is set to "0", bit 17 of the Physical outputs is always "0".
18
DO2
0: DOB (General-purpose output B) disabled
1: DOB (General-purpose output B) enabled
When this bit is set to "0", bit 18 of the Physical outputs is always "0".
19
DO3
0: DOC (General-purpose output C) disabled
1: DOC (General-purpose output C) enabled
When this bit is set to "0", bit 19 of the Physical outputs is always "0".
20 to
31
(reserved) The value at reading is undefined. Set "0" when writing.
