STMicroelectronics STM32WL5 Series User Manual

Inter-integrated circuit (I2C) interface RM0453
1106/1450 RM0453 Rev 5
Note: This register must be configured when the I2C is disabled (PE = 0).
Note: The STM32CubeMX tool calculates and provides the I2C_TIMINGR content in the I2C
Configuration window.
34.7.6 I2C timeout register (I2C_TIMEOUTR)
Address offset: 0x14
Reset value: 0x0000 0000
Access: No wait states, except if a write access occurs while a write access to this register is
ongoing. In this case, wait states are inserted in the second write access until the previous
one is completed. The latency of the second write access can be up to 2 x PCLK1 + 6 x
I2CCLK.
Bits 31:28 PRESC[3:0]: Timing prescaler
This field is used to prescale I2CCLK in order to generate the clock period t
PRESC
used for
data setup and hold counters (refer to I2C timings) and for SCL high and low level counters
(refer to I2C master initialization).
t
PRESC
= (PRESC + 1) x t
I2CCLK
Bits 27:24 Reserved, must be kept at reset value.
Bits 23:20 SCLDEL[3:0]: Data setup time
This field is used to generate a delay t
SCLDEL
between SDA edge and SCL rising edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SCLDEL
.
t
SCLDEL
= (SCLDEL + 1) x t
PRESC
Note: t
SCLDEL
is used to generate t
SU:DAT
timing.
Bits 19:16 SDADEL[3:0]: Data hold time
This field is used to generate the delay t
SDADEL
between SCL falling edge and SDA edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SDADEL
.
t
SDADEL
= SDADEL x t
PRESC
Note: SDADEL is used to generate t
HD:DAT
timing.
Bits 15:8 SCLH[7:0]: SCL high period (master mode)
This field is used to generate the SCL high period in master mode.
t
SCLH
= (SCLH + 1) x t
PRESC
Note: SCLH is also used to generate t
SU:STO
and t
HD:STA
timing.
Bits 7:0 SCLL[7:0]: SCL low period (master mode)
This field is used to generate the SCL low period in master mode.
t
SCLL
= (SCLL + 1) x t
PRESC
Note: SCLL is also used to generate t
BUF
and t
SU:STA
timings.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TEXTEN Res. Res. Res. TIMEOUTB[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11109876543210
TIMOUTEN Res. Res. TIDLE TIMEOUTA[11:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
