STMicroelectronics STM32WL5 Series User Manual

Debug support (DBG) RM0453
1344/1450 RM0453 Rev 5
38.6.11 DWT function register x (DWT_FUNCTxR)
Address offset: 0x028 + 0x010 * x, (x = 0 to 3)
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res.
MATCH
ED
Res. Res. Res. Res. DATAVADDR1[3:0]
r rwrwrwrw
1514131211109876543210
DATAVADDR0[3:0] DATAVSIZE[1:0]
LNK1E
NA
DATAV
MATCH
CYCM
ATCH
Res.
EMITR
ANGE
Res. FUNCTION[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:25 Reserved, must be kept at reset value.
Bit 24 MATCHED: comparator match (read only)
Indicates if a comparator match has occurred since the register was last read.
0: No match
1: Match occurred
Bits 23:20 Reserved, must be kept at reset value.
Bits 19:16 DATAVADDR1[3:0]: When the DATAVMATCH and LNK1ENA bits are both 1, this field can hold
the comparator number of a second comparator to use for linked address comparison.
Bits 15:12 DATAVADDR0[3:0]: When the DATAVMATCH and LNK1ENA bits are both 1, this field can hold
the comparator number of a comparator to use for linked address comparison.
Bits 11:10 DATAVSIZE[1:0]: For data value matching, specifies the size of the required data comparison.
0x0: Byte
0x1: Half word
0x2: Word
0x3: reserved
Bit 9 LNK1ENA: enable for a second linked comparator
Indicates whether use of a second linked comparator is supported (read only).
0x1: Supported
Bit 8 DATAVMATCH: enable for cycle comparison.
0x0: Address comparison
0x1: Data value comparison
Bit 7 CYCMATCH: enable for cycle count comparison on comparator 0
This field is reserved for other comparators.
0x0: No cycle count comparison
0x1: Compares DWT_COMP0R with the cycle counter, DWT_CYCCNTR.
Bit 6 Reserved, must be kept at reset value.
