STMicroelectronics STM32WL5 Series User Manual

Debug support (DBG) RM0453
1400/1450 RM0453 Rev 5
38.11.9 TPIU claim tag clear register (TPIU_CLAIMCLR)
Address offset: 0xFA4
Reset value: 0x0000 0000
38.11.10 TPIU device configuration register (TPIU_DEVIDR)
Address offset: 0xFC8
Reset value: 0x0000 0CA0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. CLAIMCLR[3:0]
rw rw rw rw
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 CLAIMCLR[3:0]: resets claim tag bits
Write:
0000: No effect
xxx1: Clears bit 0.
xx1x: Clears bit 1.
x1xx: Clears bit 2.
1xxx: Clears bit 3.
Read: Returns current value of claim tag.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res.
SWON
RZ
SWOM
AN
TCLKD
ATA
FIFOSIZE[2:0]
CLKRE
LAT
MAXNUM[4:0]
rrrrrrrrrrrr
Bits 31:12 Reserved, must be kept at reset value.
Bit 11 SWONRZ: indicates whether serial-wire output, NRZ, is supported
1: Supported
Bit 10 SWOMAN: indicates whether serial-wire output, Manchester encoded format, is supported
1: Supported
Bit 9 TCLKDATA: indicates whether trace clock plus data is supported
0: Supported
