STMicroelectronics STM32WL5 Series User Manual

Debug support (DBG) RM0453
1420/1450 RM0453 Rev 5
38.13.8 CPU2 ROM1 CoreSight peripheral identity register 1
(C2ROM1_CIDR1)
Address offset: 0xFF4
Reset value: 0x0000 0010
38.13.9 CPU2 ROM1 CoreSight component identity register 2
(C2ROM1_CIDR2)
Address offset: 0xFF8
Reset value: 0x0000 0005
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. CLASS[3:0] PREAMBLE[11:8]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 CLASS[3:0]: component ID bits [15:12] - component class
0x1: ROM table component
Bits 3:0 PREAMBLE[11:8]: component ID bits [11:8]
0x0: Common ID value
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. PREAMBLE[19:12]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 PREAMBLE[19:12]: component ID bits [23:16]
0x05: Common ID value
