Debug support (DBG) RM0453
1428/1450 RM0453 Rev 5
38.14 CPU2 breakpoint unit (BPU)
The BPU allows hardware breakpoints to be set. It contains eight comparators which
monitor the instruction fetch address and return a breakpoint instruction when a match is
detected.The CPU2 PBU does not support flash memory patch functionality.
38.14.1 BPU control register (BPU_CTRLR)
Address offset: 0x000
Reset value: 0x0000 0080
38.14.2 BPU remap register (BPU_REMAPR)
Address offset: 0x004
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
151413121110987654321 0
Res.
NUM_CODE6
NUM_CODE5
NUM_CODE4
NUM_LIT[3:0] NUM_CODE[3:0]
Res. Res.
KEY ENABLE
rrrrrrrrrrr rwrw
Bits 31:15 Reserved, must be kept at reset value.
Bits 11:8 NUM_LIT[3:0]: number of literal address comparators supported (read only)
0x0: No literal comparators supported.
Bit 14,13,12,7,6,5,4 NUM_CODE[6:0]: number of instruction address comparators supported - least significant bits
(read only)
0x8: 8 instruction comparators supported
Bits 3:2 Reserved, must be kept at reset value.
Bit 1 KEY: write protect key
A write to BPU_CTRLR register is ignored if this bit is not set to 1.
Bit 0 ENABLE: BPU enable
0: Disabled
1: Enabled
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res.
RMPSPT
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
r
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
