Debug support (DBG) RM0453
1430/1450 RM0453 Rev 5
38.14.4 BPU CoreSight peripheral identity register 4 (BPU_PIDR4)
Address offset: 0xFD0
Reset value: 0x0000 0004
38.14.5 BPU CoreSight peripheral identity register 0 (BPU_PIDR0)
Address offset: 0xFE0
Reset value: 0x0000 000C
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res. F4KCOUNT[3:0] JEP106CON[3:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 F4KCOUNT[3:0]: register file size
0x0: Register file occupies a single 4-Kbyte region.
Bits 3:0 JEP106CON[3:0]: JEP106 continuation code
0x4: Arm
®
JEDEC code
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res. Res. Res. Res. Res. Res. PARTNUM[7:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 PARTNUM[7:0]: part number bits [7:0]
0x0C: BPU part number
