Reset and clock control (RCC) RM0453
314/1450 RM0453 Rev 5
7.4.4 RCC PLL configuration register (RCC_PLLCFGR)
Address offset: 0x00C
Reset value: 0x2204 0100
Access: no wait state, word, half-word and byte access
This register is used to configure the main PLL clock outputs according to the formulas:
• f(VCO clock) = f(PLL clock input) × (PLLN / PLLM)
• f(PLL_P) = f(VCO clock) / PLLP
• f(PLL_Q) = f(VCO clock) / PLLQ
• f(PLL_R) = f(VCO clock) / PLLR
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PLLR[2:0]
PLL
REN
PLLQ[2:0]
PLL
QEN
Res. Res. PLLP[4:0]
PLL
PEN
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109 8 7 65432 1 0
Res. PLLN[6:0] Res. PLLM[2:0] Res. Res. PLLSRC[1:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:29 PLLR[2:0]: Main PLL division factor for PLLRCLK
These bits are set and cleared by software to control the frequency of the main PLL output
clock PLLRCLK. This output can be selected as system clock. These bits can be written only
if PLL is disabled.
PLLRCLK output clock frequency = VCO frequency / PLLR with PLLR = 2, 3, 4,... or 8 [VCO
frequency / (N + 1)]
000: reserved
001: PLLR = 2
010: PLLR = 3
011: PLLR = 4
100: PLLR = 5
101: PLLR = 6
110: PLLR = 7
111: PLLR = 8
Note: The software must set these bits correctly not to exceed 48 MHz on this domain in
range 1.
Bit 28 PLLREN: Main PLL PLLRCLK output enable
This bit is set and reset by software to enable the PLLRCLK output of the main PLL. It
cannot be written when PLLRCLK output of the PLL is used as system clock. In order to
save power, when the PLLRCLK output of the PLL is not used, the value of PLLREN must
be 0.
0: PLLRCLK output disabled
1: PLLRCLK output enabled
