RM0453 Rev 5 441/1450
RM0453 System configuration controller (SYSCFG)
445
11.2.12 SYSCFG CPU1 interrupt mask register 2 (SYSCFG_IMR2)
Address offset: 0x104
Reset value: 0x0000 0000
11.2.13 SYSCFG CPU2 interrupt mask register 1 (SYSCFG_C2IMR1)
Address offset: 0x108
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. PVDIM Res.
PVM3I
M
Res. Res.
rw rw
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 PVDIM: PVD interrupt mask to CPU1
0: PVD interrupt forwarded to CPU1
1. PVD interrupt to CPU1 masked
Bit 19 Reserved, must be kept at reset value.
Bit 18 PVM3IM: PVM3 interrupt mask to CPU1
0: PVM3 interrupt forwarded to CPU1
1. PVM3 interrupt to CPU1 masked
Bits 17:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
EXTI15
IM
EXTI14
IM
EXTI13
IM
EXTI12
IM
EXTI11I
M
EXTI10
IM
EXTI9I
M
EXTI8I
M
EXTI7I
M
EXTI6I
M
EXTI5I
M
EXTI4I
M
EXTI3I
M
EXTI2I
M
EXTI1I
M
EXTI0I
M
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res. Res. DACIM ADCIM
COMPI
M
AESIM Res. PKAIM Res.
FLASHI
M
RCCIM Res.
RTCW
KUPIM
RTCSS
RUIM
RTCAL
ARMIM
RTCST
AMPTA
MPLSE
CSSIM
rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 EXTIxIM: EXTIx interrupt mask to CPU2 (x = 15 to 0)
0: EXTIx interrupt forwarded to CPU2
1. EXTIx interrupt to CPU2 masked
Bits 15:14 Reserved, must be kept at reset value.
Bit 13 DACIM: DAC interrupt mask to CPU2
0: DAC interrupt forwarded to CPU2
1. DAC interrupt to CPU2 masked
