Xerox Phaser 4510 Service Manual

3-40 Phaser 4500/4510 Service Manual
Error Messages and Codes
Jam At Top; Open Top Cover To Clear
Diagnostic Error Codes
E3-1 Registration Jam 1
E3-2 Registration Jam 2
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser assembly
■ HVPS/engine logic board
■ Registration clutch
■ Transfer roller assembly
■ Print cartridge
■ Gear assembly housing
■ Fuser assembly harness
■ LVPS
■ 150-sheet feeder assembly
■ Print cartridge right guide
assembly
■ “Fuser Assembly, Power Switch” on page 10-25
■ “150-Sheet Feeder, 550-Sheet Feeder, Main
Fan” on page 10-27
■ “Print Cartridge, Transfer Roller Assembly” on
page 10-26
■ “Print Engine Wiring Diagrams” on page 10-19
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions
Yes No
1 Check the condition of the paper in the
tray.
Is the paper crumpled, damaged,
damp, or out of specification?
Replace the
paper.
Go to step 2.
2 Check paper size setup.
Does the paper size in use match the
size setup by the end guide assembly
or by the Driver on the PC?
Go to step 3. Replace the
paper, or
change the
paper size set.
3 Open the rear cover to check the paper
position.
Does the leading edge of the paper
touch the exit actuator in the fuser
assembly?
Go to step 7. Go to step 4.
4 Does the leading edge of the paper
go through the heat roller/ pressure
roller in fuser assembly?
Replace the
HVPS/engine
logic board
(page 8-73).
Go to step 5.
5 Does the leading edge of the paper
go through transfer roller assembly?
Go to step 15. Go to step 6.
6 Does the leading edge of the paper
go between metal registration roller
and rubber registration roller?
Go to step 14. Go to step 19.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
