Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 1-3
General Information
Printer Configurations
A replaceable configuration card holds configuration information that enables
or disables the network features shown in the following table.
Printer Configurations
Features
Printer Configuration
B N DT DX
Maximum print speed (letter-size
paper)
P4500:
P4510:
36 ppm
45 ppm
36 ppm
45 ppm
36 ppm
45 ppm
36 ppm
45 ppm
Memory
P4500:
P4510:
48 MB
128 MB
64 MB
128 MB
64 MB
128 MB
64 MB
128 MB
PostScript fonts 39 39 39 39 + 97
on hard
drive
PCL5e/PCL6 Yes Yes Yes Yes
Job pipelining Standard Standard Standard Standard
PDF direct print Yes Yes Yes Yes
Resolutions 600 dpi,
True 1200
dpi
600 dpi,
True 1200
dpi
600 dpi,
True 1200
dpi
600 dpi,
True
1200 dpi
USB, Parallel Yes Yes Yes Yes
10/100BaseTX Ethernet capabilities Optional Standard Standard Standard
550-sheet feeder (tray 3) Optional Optional Standard Standard
550-sheet feeder (tray 4) Optional Optional Optional Optional
Automatic 2-sided printing
(requires duplex unit)
Optional Optional Standard Standard
Hard drive Optional Optional Optional Standard
Job collation
(Requires a hard drive)
Optional Optional Optional Standard
Proof Print, Secure Print, Saved
Jobs (Requires a hard drive)
Optional Optional Optional Standard
500-sheet stacker Optional Optional Optional Standard

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
