Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 2-7
Theory of Operation
Sensors
The printer contains a number of sensors of various types that perform a
variety of functions. One group of sensors track the progress of the paper
along the paper path, and detect if a paper jam occurs. Other sensors detect
the presence of the print cartridge, stop printer activity if a door is open, and
monitor the fusing temperature. The basic printer has 18 sensors, while a
fully-optioned printer has 30 sensors.
The types of sensors in use vary with their function. In general, there are four
basic type in use:
■ Photo
■ Microswitch
■ Soft Touch Sensors (STS)
■ Magnetic
Most of the photo sensors consist of a LED in one arm of a U-shaped holder,
and a photo-transistor in the other arm. When nothing is between the arms of
the sensor, light from the LED falls on the photo-receptor, turning it on. If the
light is interrupted, the photo-transistor turns off. The on- or off-state of the
transistor is used as a signal.
The microswitches are used primarily as interlocks in the printer. They are in a
normally open state, and close when actuated. A bank of switches in a holder
is used for detecting the size of paper in use in a tray. Cams in the tray close
the switches in various combinations (see “Control of Paper Size” on
page 2-17) to send a size signal to the controller.
The Soft Touch Sensor has a known value of resistance whose sensitivity
varies with temperature.
The magnetic sensor detects the magnetic properties of the toner in the print
cartridge.
A fifth sensor in use in the printer is the antenna used to communicate with
the CRUM in the print cartridge.
The list of Sensors and interlocks that follows gives each sensor by its name,
lists which of the types it is, and briefly describes its function in the printer.
The reference column lists manual pages where illustrations show the
location of the sensor.
List of Sensors and interlocks
Name Type Function Reference
Paper low Mechanically
actuated photo
sensor
Detects low paper condition
in 550-Sheet trays 2, 3, and
4 (there is no low-paper
sensing in tray 1).
page 2-10
page 2-16
No paper Mechanically
actuated photo
sensor
Detects no paper condition
in all trays.
Page 2-16
Paper size
switches
Microswitch bank Detects the presence of a
tray and the paper size
setting of the tray.
Page 2-16
Page 2-41

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
