Xerox Phaser 4510 - Retard Roller

Phaser 4500/4510 Service Manual 8-93
FRU Disassembly
Retard Roller
(PL20.3.2)
N
o
t
e
When handling the retard roller, avoid touching the rubber surfaces of the
roller.
1.Retard roller 3.Hooks
2.Friction clutch 4.Retard spring
s4500-168
2
3
4
