Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 4-21
General Troubleshooting
Low Paper Sensor
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Low paper sensor
■ Low paper actuator
■ Bottom plate assembly
■ Low Paper 1 harness
assembly
■ LVPS
■ HVPS/engine logic board
■ “150-Sheet Feeder, 550-Sheet Feeder, Main
Fan” on page 10-27
■ “Print Engine Wiring Diagrams” on page 10-19
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Check the low paper actuator:
Install paper cassette.
Does the low paper actuator operate
smoothly when the bottom plate assembly
is pushed and released by the hand?
Does the flag go into the detection point of
the sensor when the bottom plate
assembly is released (Actuator is pushed
up), and out of the detection point when
pushed down?
Go to step 2. Replace the
low paper
actuator
(page 8-5).
2 Check the low paper sensor:
1.Enter Service Diagnostics, and from the
Sensor Tests menu select the
appropriate low paper sensor.
2.Manually actuate the low paper sensor.
Does the sensor correctly report the
position of the actuator?
Replace the
HVPS/engine
logic board
(page 8-73).
Go to step 3.
3 Check the Low Paper 1 harness assembly:
1.Remove the Low Paper 1 harness
assembly.
2.Test for continuity across J260 <=> J26.
Is it continuous?
Go to step 4. Replace Low
Paper 1
harness
assembly.
4 Replace the low paper sensor (page 8-34).
Does the problem still occur after
replacement?
Replace the
HVPS/engine
logic board
(page 8-73).
Problem
solved.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
