4-56 Phaser 4500/4510 Service Manual
General Troubleshooting
Offset Motor Assembly
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Offset motor assembly
■ Stacker motor assembly
■ Stacker PWBA
■ Stacker harness 2
■ HVPS/engine logic board
■ Stacker harness 1
■ “Stacker Signal Diagram” on page 10-37
■ “Stacker General Wiring Diagram” on
page 10-36
■ “P4500: 24 V Interlock, Rear Cover Switch,
Main Motor, Sub Fan, Exit Motor Assembly” on
page 10-21
■ “Stacker Plug/Jack Locator” on page 10-16
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Check the offset motor assembly:
Enter Service Diagnostics, and from the
Motors/Fan Test select Stacker Offset
Motor.
Does the offset assembly move back and
forth when the test is initiated?
Problem
solved.
Go to step 2.
2 Check stacker harness 2:
1.Disconnect P/J70 from stacker PWBA.
2.Remove stacker harness 2.
3.Test J70 <=> J3070 for continuity
Is the harness continuous?
Go to step 3. Replace
stacker
harness 2.
3 Check stacker harness 1:
1.Remove stacker harness 1.
2.Test J30 <=> J3070 for continuity
Is the harness continuous?
Go to step 4. Replace
stacker
harness 1.
4 Replace the offset motor assembly
(page 8-120).
Is the problem cleared?
Problem
solved.
Go to step 5.
5 Replace stacker PWBA (page 8-119).
Is the problem cleared?
Problem
solved.
Replace the
HVPS/engine
logic board
(page 8-73).

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
