Xerox Phaser 4510 Service Manual

3-8 Phaser 4500/4510 Service Manual
Error Messages and Codes
Service Diagnostics Menu Map
Print Service Menu Map Prints this page.
General Status
Provides current print engine status.
Engine ROM Version
Engine Print Counter
Engine Configuration
Print Resolution
Read Fuser Temperature
Engine Test Print Configures print parameters and initiates the
test print.
Print Test Pattern
Input Tray
Output Tray
Duplex
Print Quantity
Print Resolution
Engine NVRAM Adjustments Perform NVRAM Adjustments
essential to the performance of the printer.
Laser Power
Tray 1 Process Direction
Tray 2 Process Direction
Tray 3 Process Direction
Tray 4 Process Direction
Tray 1 Scan Direction
Tray 2 Scan Direction
Tray 3 Scan Direction
Tray 4 Scan Direction
Duplex Process Direction
Duplex Scan Direction
Motors/Fans Tests Tests the functionality of motors/fans.
Duplex Motor High
Duplex Motor Low
Exit Motor Forward
Exit Motor Reverse High
Exit Motor Reverse Low
Main Motor
Fan Motors High Speed
Fan Motors Stop
Laser Scan Motor
Stacker Motor
Stacker Offset Motor
Tray 3 Feed Motor
Tray 4 Feed Motor
Main Motor+Clutch/Sol Tests Runs main drive motor with
each individual clutch.
Motor + Registration Roll
Motor + Tray 1 Feed
Motor + Tray 2 Feed
Motor + Tray 3 Feed
Motor + Tray 4 Feed
Motor + Tray 3 Turn Roll
Motor + Tray 4 Turn Roll
Sensor Tests Tests the functionality of sensors/switches/
options by manually toggling each sensor or installing an
option.
Top Cover Switch
Rear Cover Switch
Duplex Cover Switch
Stacker Cover Switch
Paper Tray Size Read
Tray 1 Size
Tray 2 Size
Tray 3 Size
Tray 4 Size
Print Cartridge Switch
Toner Sensor
Registration Sensor
Exit Sensor (Fuser)
Duplex Sensor
Stacker Sensor
Stacker Full Sensor
Output Tray Full Sensor
Tray 2 Low Paper
Tray 3 Low Paper
Tray 4 Low Paper
Tray 1 No Paper
Tray 2 No Paper
Tray 3 No Paper
Tray 4 No Paper
Duplex Unit Presence
Stacker Unit Presence
Solenoid Tests Tests the functionality of printer solenoids.
Stacker Gate Solenoid
Clutch Tests Tests the functionality of printer clutches .
Registration Roll
Tray 1 Feed
Tray 2 Feed
Tray 3 Feed
Tray 4 Feed
Tray 3 Turn Roll
Tray 4 Turn Roll
Controller NVRAM Access Resets the PS NVRAM locations
to factory defaults.
Reset PostScript NVRAM
Factory Reset NVRAM
Exit Exits service diagnostics and reboots the printer.
For Authorized Service Personnel Use Only. Service Menu
functions are to be used by Xerox service personnel and
authorized service providers only. The printer can be damaged by
improper use of the built-i
n service tests.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
