Phaser 4500/4510 Service Manual 8-73
FRU Disassembly
HVPS/Engine Logic Board
(PL12.1.19)
Procedure:
Caution
Observe electrostatic precautions when handling the HVPS/engine logic
board and its components.
1. Remove the right cover (page 8-7).
2. Remove the HVPS shield plate (page 8-72).
3. Remove the 6 mm screw that attaches the right handle bracket to the
frame.
1.Hook 3.HVPS shield bracket
2.HVPS/engine logic board 4. Right handle bracket
s4500-151
10
11
27
13
14
15
18
1716 20 192226 24
28
30
29
31
P/J
4
1
2
3
