Xerox Phaser 4510 Service Manual

4-48 Phaser 4500/4510 Service Manual
General Troubleshooting
Optional 550-Sheet Feeder Turn Roller Clutch
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Optional 550-sheet paper
feeder turn roller clutch
■ Optional 550-sheet paper
feeder
■ 550-sheet paper cassette
■ 550-sheet feeder PWBA
■ Clutch/sensor harness 1
■ Clutch/sensor harness 2
■ Feeder harness 2
■ HVPS/engine logic board
■ LVPS
■ Feeder harness 1
■ “550-Sheet Feeder Signal Diagram” on
page 10-33
■ “550-Sheet Feeder General Wiring Diagram” on
page 10-32
■ “550-Sheet Feeder Plug/Jack Locator” on
page 10-12
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Check Clutch/Sensor harness 1 for
continuity
1.Disconnect P/J855.
2.Disconnect P/J854.
Is each cable between J855 <=> J854
continuous?
Go to step 2. Replace the
Clutch/
Sensor
harness 1.
2 Check Clutch/Sensor harness 2 for
continuity
1.Disconnect P/J85 from the 550-sheet
feeder PWBA.
2.Disconnect P/J855.
Is each cable between J85 <=> J855
continuous?
Go to step 3. Replace the
Clutch/
Sensor
harness 2.
3 Check the resistance of the turn roller
clutch:
Measure the resistance of the clutch
between P/J854-1 <=> P/J854-2.
Does the resistance measure 172 ohm +/-
10% (at 20° C)?
Go to step 4. Replace the
turn roller
clutch
(page 8-92).
4 Check the 550-sheet feeder PWBA:
1.Disconnect P/J83 from the 550-sheet
feeder PWBA.
2.Test for continuity at these points:
■ P83-3 <=> P85-3
■ P83-4 <=> P85-4
Are both continuous
Go to step 5. Replace the
550-sheet
feeder PWBA
(page 8-85).

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
