Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 3-19
Error Messages and Codes
Operating System and Application Problems
Troubleshooting tips and more information are also available on the Xerox
web site at: www.xerox.com/office/support
.
Macintosh Printing Problems
Image Never Prints
1. Printer acts as if it is receiving data, but nothing comes out of the printer
or it goes back to “Ready” mode without printing. The most likely cause is
a PostScript error occurred in the printer.
2. Power cycle the printer and try printing again.
3. Make sure that the correct Phaser 4500/4510 printer icon was selected in
the Chooser. Try printing the job again.
4. In the Chooser or the print dialog, switch background printing to off. Try
printing the job again.
5. If the error returns, turn ON the PostScript error handler through the
control panel PostScript Error Info in the Support menu, or CentreWare IS
and print the document again. Take note of the information on the error
page that just printed.
6. Select the appropriate Phaser 4500/4510 PPD with the LaserWriter
Driver or application. Not selecting the appropriate PPD can cause
PostScript errors.
7. Select a different document from the application and try to print. If the
PostScript error does not occur, then the original document may be
causing the problem.
8. Image is rotated 90 degrees.
9. In the application's Page Setup, make sure that the image is selected to
print in portrait or landscape orientation to match the document. Also,
ensure the selected paper size is correct.
Windows Printing Problems
Image Never Prints
1. Try printing a test page from the printer driver’s properties dialog box.
2. Try printing from another application.
3. Try printing to another printer.
4. Try printing from another computer.
5. If the error returns, turn ON the PostScript error handler through the
control panel PostScript Error Info in the Support menu, or CWIS and
print the document again. Take note of the information on the error page
that just printed.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
