FRU Disassembly
Options: 550-Sheet Paper Feeder
550-Sheet Paper Feeder Removal
Procedure:
1. Remove the print cartridge.
2. Pull out the 550-sheet paper cassette from the 2nd tray of the printer.
3. Remove the 550-sheet paper cassette from the optional 550-sheet paper
feeder.
1.550-sheet paper feeder 2.Latch clip
s4500-1521
2
