Xerox Phaser 4510 - Control of Paper Size

Phaser 4500/4510 Service Manual 2-17
Theory of Operation
Control of Paper Size
Paper size switch assembly The switches in this assembly send signals that
indicates the paper size setting of the tray. Cams in the bottom of the tray are
positioned by the tray’s end guide. At pre-defined paper lengths, actuators on
the side of the tray close or open the switches in a pattern that is defined in
the printer to correspond to one of the pre-set media sizes.
The following table provides the ON (1) or OFF (0) states of the switches in
the paper size switch assembly, corresponding to the paper sizes of the paper
tray.
N
o
t
e
The switches in the paper size switch assembly are denoted by “SW1”,
“SW2”, “SW3”, and “SW4”, respectively, from the front side.
Paper size
Paper Size Switch Assembly
SW1SW2SW3SW4
No cassette 0 0 0 0
Executive SEF 0 0 0 1
B5(JIS) SEF 0 0 1 1
A5 SEF 0101
Legal14”SEF 0 1 1 1
Letter SEF 1001
A4 SEF 1101
Legal13”SEF 1 1 1 1
