3-56 Phaser 4500/4510 Service Manual
Error Messages and Codes
Paper Size Jam
Diagnostic Error Code
PSE-1: Paper size mismatch
N
o
t
e
This procedure assumes that optional 550-sheet paper feeders are
installed as tray 3 and tray 4.
P4500: If tray 3 or tray 4 is reporting “Executive” when the tray is set to
“Legal,” refer to SB702 Rev A for additional troubleshooting information.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ 150-sheet feeder assembly
■ 150-sheet paper cassette
■ Registration sensor
■ Registration actuator
(Actuator B)
■ HVPS/engine logic board
■ Left tray guide
■ 550-sheet feeder assembly
■ 550-sheet paper cassette
■ “150-Sheet Feeder, 550-Sheet Feeder, Main
Fan” on page 10-27
■ “Print Engine Wiring Diagrams” on page 10-19
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Check the paper size setup.
Does the size displayed match the
size of the paper in use in the tray?
Go to step 2. Go to step 3.
2 Check the registration sensor:
1.Enter Service Diagnostics, and from
the Sensor Tests menu select the
Registration Sensor test.
2.Manually actuate the registration
sensor actuator.
Does the sensor operate correctly?
Go to step 3. Go to
“Registration
Sensor” on
page 4-17.
3 Check the paper feeding tray.
Is the paper supplied from either tray
1 or tray 2 when the error occurs?
Go to step 4. Go to step 5.
4 Check the paper cassette (1).
Are the end guide assembly, sector
gear, size rack, size switch links 1/2/
3 of the paper cassette in tray 1 or
tray 2 installed correctly?
Go to “Left Tray
Guide” on
page 4-31.
Replace the
paper cassette.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
