Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 4-45
General Troubleshooting
Optional Feeder Paper Size Switch Assembly
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Option paper size switch
assembly
■ Feeder size assembly harness 1
■ Feeder size assembly harness 2
■ Optional 150-sheet paper feeder
■ 550-sheet paper cassette
■ 550-sheet feeder PWBA
■ HVPS/engine logic board
■ “550-Sheet Feeder Signal Diagram” on
page 10-33
■ “550-Sheet Feeder General Wiring Diagram”
on page 10-32
■ “550-Sheet Feeder Plug/Jack Locator” on
page 10-12
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Check feeder size assembly harness 1:
1.Remove feeder size assembly harness 1.
2.Test each conductor between J801 <=>
J802 for continuity.
Is each cable continuous?
Go to step 2. Replace
feeder size
assembly
harness 1.
2 Check feeder size assembly harness 2 for
continuity:
1.Disconnect P/J80 from the 550-sheet
feeder PWBA.
2.Disconnect P/J801.
3.Test each conductor between J80 <=>
J801 for continuity.
Is each cable continuous?
Go to step 3. Replace
feeder size
assembly
harness 2.
3 Check the Option paper size switch
assembly.
Is the harness of Option paper size switch
assembly continuous?
Go to
“Optional
550-Sheet
Feeder PWBA
(Tray 3)” on
page 4-39, or
“Optional
550-Sheet
Feeder PWBA
(Tray 4)” on
page 4-40.
Replace the
Option paper
size switch
assembly
(page 8-82).

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
