3-52 Phaser 4500/4510 Service Manual
Error Messages and Codes
Duplex Unit Error
Diagnostic Error Code
E9-1: Duplex Unit failure
6 Enter Service Diagnostics, and from
the Motors/Fan Tests menu select
the Duplex Motor Low test.
Does duplex unit motor rotate
normally?
Replace the
HVPS/engine
logic board
(page 8-73).
Go to “Duplex
Unit Motor” on
page 4-50.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ HVPS/engine logic board
■ Duplex unit PWBA
■ Duplex unit assembly harness
■ “Duplex Unit Plug/Jack Locator” on page 10-14
■ “Duplex Unit General Wiring Diagram” on
page 10-34
■ “Duplex Unit Signal Diagram” on page 10-35
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Remove the duplex unit, re-install it,
and turn the power ON.
Does the error still occur?
Go to “Duplex
Unit PWBA” on
page 4-49.
Problem solved.
Troubleshooting Procedure (continued)
Steps Actions and Questions Yes No
To Next Page
