Xerox Phaser 4510 Service Manual

1-14 Phaser 4500/4510 Service Manual
General Information
Media and Tray Specifications
Trays Specifications
Printable
Area
All Within 4 mm of paper edge guaranteed.
Edge-to-edge printing supported.
Supported
Media Sizes
Tray 1
Trays 2-4
Tray 1
Trays 2-4
Stacker
Width: 76.2 mm (3.0 in.) ~ 215.9 mm (8.5 in.)
Width: 98.4 mm (3.9 in.) ~ 215.9 mm (8.5 in.)
Length: 127.0 mm (5.0 in.) ~ 355.6 mm (14 in.)
Length: 148.0 mm (5.8 in.) ~ 355.6 mm (14 in.)
Width: 88.9 mm (3.5 in.) ~ 215.9 mm (8.5 in.)
Length: 139.7 mm (5.5 in.) ~ 355.6 mm (14 in.)
Supported
Media
Types and
Weights
All
All
All
All
Tray 1
All
All
Bond (P4500) 60-216 g/m
2
(16-58 lb.)
(P4510) 64-216 g/m
2
(17.1-58 lb.)
Labels
Transparency
Greeting Cards 190 g/m
2
(70 lb. Cover)
Index Card Stock 60-216 g/m
2
(33-120 lb.)
Tag Stock 60-216 g/m
2
(37-133 lb.)
Cover Stock 60-216 g/m
2
(22-80 lb.)
Supported
Envelopes
All #10 Commercial (4.12 x 9.5 in.)
Monarch (3.87 x 7.5 in.)
DL (110 x 220 mm)
C5 (162 x 229 mm)
B5 (176 x 250 mm) (P4500 only)
Input Tray
Capacity
Tray 1
Trays 2-4
150 sheets
550 sheets
Based on 75 g/m
2
(20 lb. bond) paper stock.
Capacity is reduced for heavier/thicker stock.
Output Tray
Capacity
Standard
Stacker
500 sheets
500 sheets
Duplex Unit Media Specifications
Input Tray Specifications
Width Tray 1
Trays 2-4
90 - 216 mm (3.5 - 8.5 in.)
98 - 216 mm (3.9 - 8.5 in.)
Height Tray 1
Trays 2-4
140 - 356 mm (5.5 - 14.0 in.)
148 - 356 mm (5.8 - 14.0 in.)
Supported
Media
Types and
Weights
All
Bond P4500: 60-216 g/m
2
(16-58 lb.)
P4510: 64-216 g/m
2
(17.1-58 lb.)
Greeting Cards 190 g/m
2
(70 lb. Cover)
Index Card Stock 60-216 g/m
2
(33-120 lb.)
Tag Card Stock 60-216 g/m
2
(37-133 lb.)
Cover Stock 60-216 g/m
2
(22-80 lb.)

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
