Phaser 4500/4510 Service Manual 3-45
Error Messages and Codes
Jam At Rear; Open Rear Cover To Clear
Diagnostic Error Code
E6-1: Stacker Jam
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ HVPS/engine logic board
■ Stacker sensor
■ Stacker actuator
■ Lower stacker roller
■ Upper stacker roller
■ Pinch roller
■ Stacker motor assembly
■ “Stacker General Wiring Diagram” on
page 10-36
■ “Stacker Signal Diagram” on page 10-37
■ “Stacker Plug/Jack Locator” on page 10-16
Troubleshooting Procedure
Steps Actions and Questions Yes No
1 Does the error occur when the power
is turned ON?
Go to step 2. Go to step 4.
2 1.Open the stacker rear cover.
2.Check for paper at the stacker
actuator.
Is there paper at the stacker
actuator?
Remove the
paper, and then
go to step 3.
Go to “Stacker
Sensor” on
page 4-59.
3 Does the error occur when the power
is turned ON?
Go to “Stacker
Sensor” on
page 4-59.
Go to step 4.
4 1.Remove the stacker, then re-install
it.
2.Enter Service Diagnostics, and from
the Engine Test Print menu
select Output Tray, then select
Stacker.
3.From the Engine Test Print menu
select Print Test Pattern.
Does the error still occur when the
stacker is selected as the output
tray?
Go to step 5. Problem solved.
5 Is the test print being directed to the
Standard Output tray instead of the
stacker.
Go to “Gate
Solenoid
Assembly” on
page 4-57.
Go to step 6.
To Next Page
