Phaser 4500/4510 Service Manual 5-3
Print-Quality Troubleshooting
Analyzing Test Prints
The test print shown on page 5-5 is used to evaluate and ensure that the
printed image meets the printer specifications. To make the test print:
1. From the main menu, scroll to Troubleshooting, then press the OK
button.
2. Scroll to Print Quality Problems, then press the OK button.
3. Scroll to Test Prints, then press the OK button.
N
o
t
e
Ensure that Edge-to-Edge printing is set to Off in the Job Defaults Menu
before starting the test print. Otherwise, the image is shifted left.
Print-Quality Defect Definitions
The Test Print (shown on page 5-5) is used to evaluate each of the print-
quality parameters. Each area of the test pattern is used for a print-quality
parameter. The Test Print analysis procedures explain each of the areas and
the print-quality parameters. Further assistance in evaluating image-quality
problems is available in the Troubleshooting Print Quality Page in the Print
Quality Problems section of the Troubleshooting menu. These pages
contain detailed explanations of print-quality and image-quality problems
along with possible causes and solutions for the problems.
Print-Quality Defect Definitions
Defect Definitions Go To:
LIGHT PRINTS: The overall image density is too light. page 5-15
BLANK PRINTS: Prints with no visible image. page 5-17
BLACK PRINTS: The print is completely covered with toner and has no
visible image.
page 5-19
VERTICAL DELETIONS: There are areas of the image that are extremely
light or missing entirely. These areas run vertically along the page in the
direction of paper movement.
page 5-20
HORIZONTAL DELETIONS: There are areas of the image that are
extremely light or missing entirely. These areas run horizontally across
the page in the direction of scanning.
page 5-22
VERTICAL STREAKS: Extraneous dark lines/bands in the process
direction.
page 5-25
HORIZONTAL STREAKS: Extraneous dark lines/bands in the direction
of scan.
page 5-27
SPOTS: There are spots of toner on the page. page 5-12
UNFUSED IMAGE: Part of or all of the image is unfused. Refer to the
specification.
page 5-31
DAMAGED PRINTS: Creases, wrinkles, excessive curl, cuts, folds or
embossed marks.
page 5-34

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
