5-4 Phaser 4500/4510 Service Manual
Print-Quality Troubleshooting
RESOLUTION: At 600 dpi, the two pixel lines and halftone patches
cannot be reproduced clearly on the print.
page 5-8
SPOT DELETIONS: Solid areas are marked with irregular white areas. page 5-36
REPEATING DEFECTS: Recurring marks, spots, lines, or voids. page 5-38
RESIDUAL IMAGES: The image from a previous print, which was not
removed during the cleaning process, has been developed on the
current print.
page 5-39
BACKGROUND: Uniform toner contamination in non image areas. See
the Background specification.
page 5-41
UNEVEN DENSITY: The text/line darkness and solid area density image
varies across the print.
page 5-42
SKEWED IMAGE: Angular displacement of the image from its intended
position on the print. See the specification.
page 5-43
REGISTRATION (lead edge to trail edge): Displacement of the image, in
the process direction, from its intended position on the print.
(inboard to outboard): Displacement of the image, in the direction of
scan, from its intended position on the print.
page 5-46
SKIPS / SMEARS: Skip-Loss or stretching of the image in bands across
the process direction.
Smear-The distortion of the image in bands across the process
direction that cause it to appear to be blurred or compressed.
page 5-48
Print-Quality Defect Definitions (continued)
Defect Definitions Go To:
