Xerox Phaser 4510 - Duplex Unit Plug;Jack Locator

10-14 Phaser 4500/4510 Service Manual
Wiring Diagrams
Duplex Unit Plug/Jack Locator
P/J Locator Table
P/J Coordinates Remarks
50 G-304 Connects the duplex unit harness and duplex unit PWBA
51 G-304 Connects the duplex unit motor and duplex unit PWBA
52 G-304 Connects the duplex unit harness COVER and duplex unit
PWBA
53 E-303 Connects the duplex unit harness SNR and duplex unit
PWBA
54 E-303 Connects the duplex unit fan and duplex unit PWBA
56 G-305 Connects the duplex unit harness ground and duplex unit
PWBA
520 H-305 Connects the duplex unit switch and duplex unit harness
530 C-303 Connects the duplex unit sensor and duplex unit sensor
harness
560 H-307 Connects the duplex unit harness ground and Ground Plate
Assembly
2750 I-304 Connects the duplex unit harness and LVPS harness
assembly
