Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 3-21
Error Messages and Codes
Troubleshooting Procedures for Error Messages and Codes
The Error Message Summary tables that follow are the lead-ins to the
procedures that follow in subsequent pages. There are two tables because
the Engine Error and Jam Error codes are not the same for both printers. The
Control Panel Message column lists the error message that appears on the
control panel when the error occurs during normal operation. The Diagnostic
Message column lists the error message that appears when the error occurs
during use of Service Diagnostics. The Engine Errors column lists the code
number that appears in fault histories, either on the control panel display
when you view Engine Error History or in the Service Usage Profile at line
262 Engine Error Log. The Jam Errors column lists the code that appears on
the control panel display when you view Jam History for the Phaser 4500 or
the Printer Status page for the Phaser 4510. The Procedure to Use column
lists the page number of the troubleshooting procedure for that error.
For the Phaser 4510 printer, refer to the “Service Code Table” on page A-6,
which maps the engine error and jam error codes to specific error messages.
The procedures that follow the table are named with the messages that
appear on the control panel when an error occurs. The error codes listed in
the procedure are the fault codes displayed in Service Diagnostics along with
the fault condition that produced the code.
Phaser 4500 Error Message Summary
Control Panel Message Diagnostic Message
Engine
Errors
Jam
Errors
Procedure
to Use
“Engine Logic Board
NVRAM Failure\
Press i”
U6: NVM Fail 3 — Go to
page 3-33.
“Main Motor Failure\
Press i”
U1: Motor Fail/Power
Off
2—Go to
page 3-28.
“Laser Unit Failure\
Press i”
Laser Fails at warm-up
U2-1: Laser Fail/Power
Off
5—Go to
page 3-29
“Laser Unit Failure\
Press i”
Laser Fails Motor
Speed
U2-2: Laser Fail/Power
Off
5—Go to
page 3-29
“Laser Unit Failure\
Press i”
LD Power is high
U2-3: Laser Fail/Power
Off
5—Go to
page 3-29
“Laser Unit Failure\
Press i”
LD Power is low
U2-4: Laser Fail/Power
Off
5—Go to
page 3-29
“Fuser Failure\ Press i” Fuser High Temp
U4-1: Fuser Fail/Power
Off
1—Go to
page 3-30

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
