Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 1-11
General Information
Printer Specifications
Physical Dimensions and Clearances
Print Engine Dimensions Value
Height 404 mm (15.9 in.)
Width 422 mm (16.6 in.)
Depth
Depth with paper cassette extended
465 mm (18.3 in.)
524 mm (20.7 in.)
Weight (with 10-K print cartridge) 20.5 kg (45.2 lbs.) (P4500)
23.2 kg (51.0 lbs.) (P4510)
Clearances Value
Top 400 mm (16 in.)
Left 210 mm (8 in.)
Right 300 mm (12 in.)
Front 480 mm (19 in.)
Rear (with duplex unit installed) 230 mm (9 in.)
Total Height requirement 820 mm (32 in.)
Add 9.6 cm (3.75 in.) for
each 550-sheet feeder
Mounting surface level tolerance ± 5°
550-Sheet Feeder Dimensions Value
Height (to top of feeder assembly) 143 mm (5.6 in.)
Width 422 mm (16.6 in.)
Depth
Depth with paper cassette extended
452 mm (17.8 in.)
510 mm (20.1 in.)
Weight 6.3 kg (13.9 lbs.)
Duplex Unit Dimensions Value
Height 219 mm (8.6 in.) (P4500)
238 mm (9.4 in.) (P4510)
Width 352 mm (13.8 in.)
Depth 96 mm (3.8 in.) (P4500)
146 mm (5.8 in.) (P4510)
Weight 1.9 kg (4.2 lbs.)
Stacker Dimensions Value
Height 226 mm (8.9 in.)
Width 418 mm (16.4 in.)
Depth
Depth with stacker tray extended
312 mm (12.3 in.)
382 mm (15.1 in.)
Weight 2.6 kg (5.7 lbs.)

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
