Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 3-15
Error Messages and Codes
System Start-Up and POST
Power On Self Test (POST)
The following tests are performed when the printer is powered on, after the
boot loader runs, and before the operating system is loaded and initialized.
POST diagnostics are intended to provide a quick means of isolating a
defective subsystem associated with the image processor board and SDRAM.
POST returns control to the boot loader and the operating system is loaded.
The operating system then loads the imaging processing software. If POST
detected any soft errors, a message is printed in a gray box on the start page.
If POST detects any hard errors, both the control panel and health LED blink
the error code pattern, see “LED Blink Patterns” on page 3-16.
POST Startup indications
■ At power-on the hardware default is to turn on the IP board ‘health’ LED.
■ The image processor board ‘health’ LED is turned off.
■ The control panel display is reset (addressable area becomes “gray”).
■ The Red LED turns on.
■ The backlight is turned on (normal intensity), with nominal contrast
display for 1/4 second.
■ The control panel display area is turned on, dark black for 1/4 second.
■ The control panel display is cleared for 1/4 second.
■ The backlight is turned off with nominal intensity for 1/4 second.
■ The POST Vn.nn message appears, and tests are quickly executed.
■ If any tests fail, the control panel screen freezes with the name of the test
displayed and the line posted is “Call Customer Service”.
■ After the POST tests have finished running, the Xerox ‘splash screen’ is
posted to the control panel and PostScript begins initialization.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
