Xerox Phaser 4510 Service Manual

2-8 Phaser 4500/4510 Service Manual
Theory of Operation
Registration
sensor
Mechanically
actuated photo
sensor
Detects the paper as it
reaches the registration
rollers.
Page 2-10
Page 2-16
Toner sensor Magnetic sensor Detects the presence of
toner in the print cartridge.
Page 2-16
Exit sensor Mechanically
actuated photo
sensor
Detects paper as it leaves
the fuser.
Page 2-22
Output tray full
sensor
Mechanically
actuated photo
sensor
Detects when the standard
output tray is full.
Page 2-27
Temperature
sensor
Soft Touch Sensor Two of these monitor the
temperature of the Heat
roller.
Page 2-22
Rear cover
switch
Microswitch Interrupts +24 V to the main
motor when the rear exit
cover is open; in series with
24 V interlock.
Page 2-30
24 V interlock Microswitch Interrupts +24 V to the main
motor when the top cover is
open; in series with rear
cover switch.
Page 2-30
Top cover switch
(P4500 only)
Microswitch Interrupts INTERLOCK BEF
to indicate the top cover is
open.
Page 2-30
Laser interlock
(P4500 only)
Microswitch Interrupts +5 V to laser
diode; in series with 5 V
interlock switch.
Page 2-30
5 V interlock Microswitch Interrupts +5 V to laser
diode. In series with laser
interlock.
Page 2-30
Start of scan
sensor
Photo Detects the laser beam at the
start of a scan.
Page 2-20
Fuser
thermostat(s)
Thermostatic
switche(s)
Interrupt AC power to the
fuser heater in overtemp
condition; P4500: two
switches in series; P4510:
single switch.
Page 2-22
Stacker rear
cover switch
Microswitch Signals the HVPS/engine
logic board that the stacker
rear cover is open.
Page 2-38
Stacker sensor Mechanically
actuated photo
sensor
Senses the presence of
paper in the stacker.
Page 2-38
List of Sensors and interlocks
Name Type Function Reference

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
