Phaser 4500/4510 Service Manual 8-59
FRU Disassembly
3. Remove the four 6 mm machine screws that attach the gear assembly
plate to the frame.
4. Remove the gear assembly plate.
5. Release the locking tab of the bottom side of the connector of the fuser
harness assembly from the frame.
6. Remove gear 9 from the shaft on the frame.
Replacement Note:
■ When installing, engage the gears of the gear assembly housing, main
motor, and gear assembly plate. After assembling, rotate the main motor
by hand to check the engagement of the gears.
To Next Page
