Phaser 4500/4510 Service Manual 8-103
FRU Disassembly
Procedure:
1. Remove the left cover (page 8-96).
2. Remove the right cover (page 8-97).
3. Remove the top cover (page 8-98).
4. Unplug the harness connectors from P50, P51, P52, P53 and P54) on the
duplex unit PWBA.
Note
The P55 connector is unused.
5. Remove the two screws (one tapping, 8 mm; one machine, 6 mm) that
attach the duplex unit PWBA to the duplex unit housing cover.
6. Remove the duplex unit PWBA.
To Next Page
