Phaser 4500/4510 Service Manual 9-5
Parts Lists
FRU Parts List 1.1 Covers
No. Name/Description Part Number
1 OPERATION PANEL (control panel) P4500: 848K06471
P4510: 848E17860
2 COVER OPEN (top cover) 802E47286
3 COVER REAR P4500: 604K16463
P4510: 604K37141
4 COVER RIGHT 802E49524
5 COVER FRONT P4500: 802E63802
P4510: 848K02990
6 COVER LEFT 802E49492
7 COVER TOP ASSY
8 COVER STOPPER P4500: 802E61863
P4510: 848E09200
9 STOPPER OPEN
10 HARNESS ASSY PANEL 962K22731
11 SWITCH I/L ASSY (J144, J411) P4500 only: 110K11894
13 COVER EXIT 500 (also listed as 10.1 P4500: 802E47345
P4510: 604K38280
14
FAN MAIN (Phaser 4510)
a
P4500: see PL 12.1.10
P4510: 127E84180
15 SEAL REAR FAN (Phaser 4510)
99 KIT TOP COVER (with 7, 9) P4500: 604K15384
P4510: 604K39040
a The main fan for the Phaser 4500 is listed in PL12.1 on page 9-27.
