Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 9-29
Parts Lists
PL12.1 Electrical
No. Name/Description Part Number
1 HARNESS ASSY LVPS (J10, J11, J18, J27,
CNPOW, J141-J42, J41, J1821, P270, J102,
P2750, J40, P142, P144, J411, J400)
2 PLATE TIE FRONT
3 SHIELD PLATE LVPS
4 PWBA EXIT MOTOR 160K91992
5 LVPS 110 V P4500: 105K20395
P4510: 105K22181
LVPS 220 V P4500: 105K20404
P4510: 105K22191
6 POWER SWITCH 110K11570
7 INTERLOCK S/W REAR (J44) P4500: 110K11624
P4510: 110K14750
8A HARNESS ASSY AC 110V (J48, J480)
8B HARNESS ASSY AC 220V (J48, J480)
10
FAN MAIN (J244)
a
P4500: 127E83610
P4510: see PL 1.1.14
11 PANEL REAR
12 BRACKET HANDLE R
13 Image Processor PWBA (ESS) P4500: 960K35050
P4510: 960K41801
14 SHIELD ASSY ESS
15 SHIELD ASSY WINDOW
16 FFC ASSY ESS (P28-CNVD) 962K13460
17 HARNESS ASSY CHUTE (J24-P245, P248)
18 SHIELD PLATE HVPS
19 HVPS/MCU 110 V P4500: 675K30892
P4510: 675K44385
HVPS/MCU 220 V P4500: 675K30902
P4510: 675K44395
20 MYLAR HVPS
21 HARNESS ASSY FDR1 (J20-P2083) (feeder
harness 1)
a The main fan for the Phaser 4510 is listed in PL 1.1 on page 9-4.

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
