9-32 Phaser 4500/4510 Service Manual
Parts Lists
Parts List 20.1 550-Sheet Paper Feeder (1/2)
No. Name/Description Part Number
1 COVER RIGHT PLATE
2 COVER FRONT
3COVER LEFT PLATE
4 EARTH PLATE
5 HARNESS ASSY FDR2 (J83-JD2083) (feeder harness
2)
6 SPRING EARTH TOP
7 FRAME TOP ASSY
8 DRIVE ASSY OPT FDR (with 9-17) P4500: 007K87655
P4510: 007K94810
9 BRACKET ASSY DRIVE
10 GEAR OPT FDR2
11 GEAR OPT FDR3
12 GEAR OPT FDR4
13 GEAR OPT FDR5
14 GEAR OPT FDR6
15 PLATE FEEDER DRIVE
16 CLAMP-5 V0
17 MOTOR FEEDER (J820)
18 OPT ASSY SIZE (J800) (paper size switch assembly) 110K11635
19 HARNESS ASSY SIZE FDR1 (P802-J801)
20 PLATE EARTH 550
21 FRAME CVR L550
22 FOOT
23 FRAME BASE FRONT
25 COVER RE550
26 HARNESS ASSY FDR5 (J84-PD8483) (feeder
harness 5)
27 PLATE CST LOCK
28 FRAME CVR R550
29 HLD LOW PAPER ASSY (P810) (with 30-33) 019K98503
30 SENSOR LOW PAPER (P810) 930W00113
