Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 9-35
Parts Lists
Parts List 20.2 550-Sheet Paper Feeder (2/2)
No. Name/Description Part Number
1 550 FEEDER OPTION (with 4-23, 25-34) P4500: 022K66125
P4510: 022K74442
4 SUPPORT NUDGER
5 HOLDER LEFT
6 ACTUATOR NO PAPER
7 GEAR IDLER NUDGER
8 HOLDER RIGHT
9 SHAFT NUDGER
10 GEAR NUDGER 059K25270
11 ROLL ASSY NUDGER (part of 99)
12 ROLL ASSY FEED (part of 99)
13 CLUTCH ONEWAY FEED 005E16941
14 ROLL ASSY TURN
15 CLUTCH ONEWAY NUDGER 005E16951
16 SHAFT FEED
17 BEARING NUDGER 013E22571
18 CHUTE TOP ASSY
19 COVER ACTUATOR
20 CHUTE BTM
21 CLUTCH ASSY PH (J853) (feed clutch) 121K28511
22 CLUTCH PR-REGI (J854) (turn roller clutch) 121K28511
23 BEARING FEEDER
25 CHUTE OUT
26 SPRING EARTH (Ground Spring)
27 SPRING PINCH TURN
28 ROLL PINCH TURN
29 PLATE TIE
30 CLAMP-5 V0
31 HARNESS ASSY CLSNR1 (J855-J852, P853, P854)
32 COVER HARNESS R
33 SENSOR NO PAPER (P852) 930W00113
34 CHUTE 550 LOWER
99 Roller Kit (with 11 or 12, qty. 3) 604K19890

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
