Phaser 4500/4510 Service Manual 9-37
Parts Lists
Parts List 20.3 Optional 550-Sheet Paper Cassette
No. Name/Description Part Number
1 COVER CST 802E47191
2 ROLL ASSY RETARD (part of 99)
3 FRICTION CLUTCH
4 SHAFT RETARD
5 HOLDER RETARD
6 SPRING RETARD P4500: 809E37500
P4510: 809E74400
7 GEAR PB L
8 GEAR BTM ONEWAY
9SHAFT PB
10 PLATE ASSY BTM
11 GUIDE ASSY SD L550
12 GEAR PINION
13 GUIDE ASSY SD R550
15 GEAR LOCK ONEWAY
16 HOUSING TOP 550
17 LOCK EXTENSION
18 SPRING BTM UP 550
19 PLATE GEAR LOCK 550
20 GEAR PB R
21 RACK BTM LOCK 550
22 COVER BTM UP 550
23 GEAR LOCK PINION
24 SPRING BTM LOCK
25 GEAR BTM LOCK
26 GEAR LEVER LOCK
27 LEVER BTM LOCK
28 SPRING STOPPER GEAR
29 STOPPER GEAR
30 PLATE SUPPORT
31 COVER EXTENSION
32 SUPPORT GUIDE IND
34 GUIDE INDICATOR 1
35 GUIDE INDICATOR 2
36 GUIDE INDICATOR 3
37 LOW INDICATOR
