Xerox Phaser 4510 Service Manual

9-44 Phaser 4500/4510 Service Manual
Parts Lists
Parts List 23.1 Stacker
No. Name/Description Part Number
1 COVER OCT (with 3) (stacker cover) 604K15645
2 WEIGHT 036E91551
3 ELIMINATOR ASSY
4 COVER REAR
5 SCREW THUMB
6 MOTOR ASSY OCT (J71) (stacker motor assembly) 127K39351
7 GEAR 45 007E74830
8 GEAR 19/37 007E74840
9 BRACKET MOTOR OCT (stacker motor bracket)
10 SUPPORT OCT LEFT (left stacker support)
11 GEAR 19 007E74821
12 BEARING OFFSET 013E22030
13 BEARING ROLL 013E22021
14 HOUSING OCT (stacker housing)
15 ACTUATOR FULL STACK 120E21663
16 ROLL OCT LOWER (lower stacker roller) 059K25121
17 CHUTE INLET
18 S/W REAR COVER (P740) 110E10200
20 MOTOR ASSY OFFSET (J72) 127K39341
22 PWBA OCT (stacker PWBA) 160K86745
23 SUPPORT OCT RIGHT (right stacker support)
24 CLAMP MINI
25 HARNESS ASSY OCT 2 (J70-JD3070) (stacker
harness 2)
26 HARNESS ASSY OCT SNR (J73-J730) (stacker
sensor harness)
27 SOLENOID ASSY GATE (J75) 121K28672
28 GEAR CAM 007E74810
29 HARNESS ASSY REAR COVER (J74-J740)
30 SENSOR OCT (P730) (stacker sensor) 930W00113
31 ACTUATOR OCT (stacker actuator) 120E21270
32 SPRING ACTUATOR 809E37332
33 SPRING PINCH 809E37341
34 ROLL PINCH 059E97541
35 CHUTE OFFSET ASSY (with 13, 36-39) 054K23313
36 ROLL OCT UPPER (Upper stacker roller)

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
