10-18 Phaser 4500/4510 Service Manual
Wiring Diagrams
Represents a connector. The connector and PIN
Nos. are shown at the upper and lower parts
respectively.
“P,-” indicates the plug side of the connector.
“J,>” indicates the jack side of the connector.
Represents a connection terminal with a plate
spring on the printed circuit board. The connector
No. is indicated inside the box.
Represents a connector directly connected to the
printed circuit board. The connector No. is
indicated inside the box.
Represents a part.
“PL X.Y.Z” indicates the item “Z” of the plate (PL)
“X.Y” described in Chapter 5 “Parts List.”
Represents a functional part within a part, and
indicates the name of the functional part.
Indicates a reference item associated with the
section.
Symbol Description
