Xerox Phaser 4510 Service Manual

10-22 Phaser 4500/4510 Service Manual
Wiring Diagrams
INTERLOCK BEF Signal indicating that the top cover is open. This signal goes High
when the top cover is open.
FAN ALARM Sub Fan monitor signal. If a trouble occurs, this signal goes High.
EXIT /INB Excitation signal for Exit Motor. Phase /B.
EXIT /INA Excitation signal for Exit Motor. Phase /A.
EXIT INB Excitation signal for Exit Motor. Phase B.
EXIT INA Excitation signal for Exit Motor. Phase A.
EXIT CUR A Current-switching signal for Exit Motor.
EXIT CUR B Current-switching signal for Exit Motor.
A and B Current output to each winding of Exit Motor. Phases A and B.
/A and /B Current output to each winding of Exit Motor. Phases A
and B.
/PRFD Prefeed signal. This is effective only when /RDY is Low.
/CCLK Clock signal. This is sent out simultaneously with /STA or /CMD.
/CMD Command signal. When /CBSY is Low, it is sent out from the
controller in synchronism with /CCLK.
/CPRDY Ready signal for the controller power supply. This signal goes
Low when the controller power supply is ON and, at the same
time, initialization of the CPU is completed. When a trouble occurs
with the CPU, the signal goes High.
/START Print start signal. This is effective only when /RDY is Low.
/CBSY Command busy signal. This goes Low when /CMD is sent out
(except when /SBSY is Low or /PPRDY is High).
/STA Status signal. Status is sent in synchronism with /CCLK when /
SBSY is Low.
/SBSY Status busy signal. This signal is Low when the printer is sending
/STA (except when /CBSY is Low or /CPRDY is High).
/TOP Vertical sync signal for image data. This is periodically sent out
when Laser Unit Motor is in operation.
/RDY Ready signal. This signal is Low in a standby state where
reception of /START is awaited.
/PPRDY Ready signal for the printer power supply. This goes Low when
the printer power supply is turned on and initialization of the CPU
is completed. This signal goes High when the MCP detects an
error.
/BD Horizontal sync signal for image data. This is periodically sent out
when Laser Unit Motor is in operation.
/SLP Control signal for LVPS. This goes Low in power saving mode.
/VDO1 Image data signal. This is sent out in synchronism with /TOP and /
BD. This signal goes High (White) for other than effective data.
/VDO2
Signal line
name
Description

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
