Xerox Phaser 4510 Service Manual

2-24 Phaser 4500/4510 Service Manual
Theory of Operation
Fuser Warm-Up
The halogen lamp is turned on when the fuser warm-up begins. When the
surface temperature of the heat roller (detected by the thermistor) reaches the
fuser control temperature (standby temperature), the fuser warm-up is ended.
Fuser Temperature Cycling
The fuser temperature does not remain at a single, constant value, but varies
within a temperature range. There are several ranges, which are summarized
in the table. Except for Standby, the setting is determined by the media type
selection.
Phaser 4500 Fuser Cycling Temperatures
Setting
Temperature
Standby Lamp ON 180° C
Lamp OFF 185° C
Medium 1-100 pages:
Lamp ON 205° C
Lamp OFF 206° C
101-120 pages:
Lamp ON 205° C
Temp. decreases
by.25° C per page
120 + pages:
Lamp ON 200° C
Lamp OFF 201° C
High Lamp ON 210° C
Lamp OFF 211° C
Extra High Lamp ON 215° C
Lamp OFF 216° C
Low Lamp ON 185° C
Lamp OFF 186° C
Phaser 4510 Fuser Cycling Temperatures
Setting
Temperature
Standby Lamp ON 180° C
Lamp OFF 185° C
Low 1-50 pages:
Lamp ON 190° C
Lamp OFF 191° C
51-62 pages:
Lamp ON 190° C
Temp. decreases by
.25° C per page
63 + pages:
Lamp ON 187° C
Lamp OFF 188° C
Medium 1-50 pages:
Lamp ON 210° C
Lamp OFF 211° C
51-70 pages:
Lamp ON 210° C
Temp. decreases by
.25° C per page
71 + pages:
Lamp ON 205° C
Lamp OFF 206° C
High Lamp ON 212° C
Lamp OFF 213° C
Very High Lamp ON 214° C
Lamp OFF 215° C
Extra High Lamp ON 187° C
Lamp OFF 188° C
Very Low Lamp ON 185° C
Lamp OFF 186° C

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
