Phaser 4500/4510 Service Manual 2-41
Theory of Operation
1.Optional 550-sheet feeder 5.Low paper sensor
2.Turn roller 6.Low paper actuator
3.No paper actuator 7.550-sheet feeder PWBA
4.No paper sensor 8.Option paper size switch assembly
s4500-036
8
1
2
3
4
5
6
7
